WaterGuard Plus Washdown Fixtures
- WILL NOT LEAK
|
Download: Washdown FixturesApplications include Product Inspection, Food Plants, Supermarket Produce Misting Areas, Amusement Parks, Car Washes, Parking Garages, Retail, Food Processing, Seacoast Areas, Tunnels, Greenhouses, Signage, Water Treatment Plants, Bridges, Shopping Malls, Decorative Lighting and Corrosive Areas. Casing manufactured from XYLEX 8300 HP. All fixtures now come standard with mirror-like reflectors, and are able to withstand high pressure washdown up to 1200PSI. Parts list and photo metrics available upon request. All products IP67 Rated. Limited One-Year Warranty. Temperature rated from -20°F to 180°F. |
|
WGP50 Single T5 Lamp Series
UL listed 1598. UL-EPH Certified. Standard fixture includes two heavy duty non-metallic fixed mounting brackets, HF Electronic Program Start Universal Ballast 120V to 277V 50/60HZ, Factory pre-wired with 8 foot black cord, High efficiency reflector system to increase foot candles directly under fixture, and a Single 4100 Kelvin T5 safety coated lamp. Other Kelvin temperature lamps available upon request. Optional suspension mounting methods available at additional cost. WaterGuard fixtures should be cleaned with a mild soap and water solution. Do not use industrial cleaners or solvents. Not recommended for permanent immersion.
| 50MM / 2.00 INCH DIAMETER LAMP SPECS | |||
| Length | Part Number | Description | Multi-Voltage |
| 1 Foot Single T5 Lamp | WGP511 | 8 Watt - Miniature Bi-Pin - T5 Lamp Length - 12 inches Fixture Length - 14 inches |
120v/60Hz (only available in 120V) |
| 2 Foot Single T5 Lamp | WGP512 | 14 Watt - Miniature Bi-Pin - T5 Lamp Length - 22 inches Fixture Length - 24.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 3 Foot Single T5 Lamp | WGP513 | 21 Watt - Miniature Bi-Pin - T5 Lamp Length - 34 inches Fixture Length - 36.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 4 Foot Single T5 Lamp | WGP514 | 28 Watt - Miniature Bi-Pin - T5 Lamp Length - 46 inches Fixture Length - 48.5 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 5 Foot Single T5 Lamp | WGP515 | 35 Watt - Miniature Bi-Pin - T5 Lamp Length - 58 inches Fixture Length - 60.375 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
WGP70 Single T8 Lamp Series
UL listed 1598. UL-EPH Certified. Standard fixture includes two heavy duty non-metallic fixed mounting brackets, HF Electronic Program Start Universal Ballast 120V to 277V 50/60HZ, Factory pre-wired with 8 foot black cord, High efficiency reflector system to increase foot candles directly under fixture, and a Single 4100 Kelvin T8 safety coated lamp. Other Kelvin temperature lamps available upon request. Optional suspension mounting methods available at additional cost. WaterGuard fixtures should be cleaned with a mild soap and water solution. Do not use industrial cleaners or solvents. Not recommended for permanent immersion.
| 70MM / 2.75 INCH DIAMETER LAMP SPECS | |||
| Length | Part Number | Description | Multi-Voltage |
| 2 Foot Single T8 Lamp | WGP712 | 17 Watt - Miniature Bi-Pin - T8 Lamp Length - 24 inches Fixture Length - 27.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 3 Foot Single T8 Lamp | WGP713 | 25 Watt - Miniature Bi-Pin - T8 Lamp Length - 34 inches Fixture Length - 39.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 4 Foot Single T8 Lamp | WGP714 | 32 Watt - Miniature Bi-Pin - T8 Lamp Length - 48 inches Fixture Length - 51.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 5 Foot Single T8 Lamp | WGP715 | 40 Watt - Miniature Bi-Pin - T8 Lamp Length - 60 inches Fixture Length - 63.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
WGP70 TWO & FOUR LAMP T5 LAMP SERIES
UL listed 1598. UL-EPH Certified. Two Lamp or Four Lamp standard fixture includes two heavy duty non-metallic fixed mounting brackets or three brackets for the four lamp fixture, HF Electronic Program Start Universal Ballast 120V to 277V 50/60HZ, Factory pre-wired with 8 foot black cord, High efficiency reflector system to increase foot candles directly under fixture, and a Single 4100 Kelvin T5 safety coated lamp. Other Kelvin temperature lamps available upon request. Optional suspension mounting methods available at additional cost. WaterGuard fixtures should be cleaned with a mild soap and water solution. Do not use industrial cleaners or solvents. Not recommended for permanent immersion.
| 70MM / 2.75 INCH DIAMETER TWO LAMP SERIES SPECS | |||
| Length | Part Number | Description | Multi-Voltage |
| 2 Foot Double T5 Lamp | WGP722 | 14 Watt - Miniature Bi-Pin - T5 Lamp Length - 22 inches Fixture Length - 27.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 3 Foot Double T5 Lamp | WGP723 | 21 Watt - Miniature Bi-Pin - T5 Lamp Length - 34 inches Fixture Length - 39.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 4 Foot Double T5 Lamp | WGP724 | 28 Watt - Miniature Bi-Pin - T5 Lamp Length - 46 inches Fixture Length - 51.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 5 Foot Double T5 Lamp | WGP725 | 35 Watt - Miniature Bi-Pin - T5 Lamp Length - 58 inches Fixture Length - 63.75 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
| 70MM / 2.75 INCH DIAMETER FOUR LAMP SERIES SPECS | |||
| Length | Part Number | Description | Multi-Voltage |
| 8 Foot Four Lamp T5 | WGP748 | 28 Watt - Miniature Bi-Pin - T5 Lamp Length - 46 inches Fixture Length - 96 inches |
120v/60Hz 240v/50Hz 277v/60Hz |
Mounting Brackets
Each EncapSulite WaterGuard Plus Fluorescent Fixture includes two non-metallic mounting brackets.
 |
 |
WGP50 Mounting Bracket |
WGP70 Mounting Bracket |
| Sanitation | |
 |
 |
| ANSI/NSF 2 Fabricated Food Service Equipment 12SS “For Splash Zone Only” |
ANSI/NSF 2 12SS |
